Canon iR3245 Series User Manual

Chapter 16
16-22
16.3.3 Jam codes (Finisher)
0019-0660
iR3225 / iR3225N / iR3235 / iR3235N / iR3245 / iR3245N
- Finisher-AE1/AE2
T-16-18
- Finisher-S1
T-16-19
16.4 Alarm Code
16.4.1 Alarm Code
0019-8811
iR3225 / iR3225N / iR3235 / iR3235N / iR3245 / iR3245N
T-16-20
0071 - -
0073 Release motor HP sensor SR11
0084 Registration sensor SR1
0090 Sensor in reader unit -
0091 Sensor in reader unit -
0092 Cover open/closed sensor SR6
0093 Cover open/closed sensor SR6
0094 Registration sensor, Read sensor, Delivery reversal sensor SR1,SR2,SR3
0095 - -
Code Type of Sensor Sensor No. / Type of Error
1011 inlet path sensor feed delay jam PI103
1014 feed path sensor feed delay jam PI104
1091 feed delay jam PI18
1092 delivery delay jam PI11
1093 saddle inlet sensor feed delay jam PI22
1121 inlet path sensor feed stationary jam PI103
1124 feed path sensor feed stationary jam PI104
1205 inlet path sensor timing jam PI103
1307 power-on jam PI33, PI104
1387 power-on jam PI8,PI11,PI17,PI18,PI19,PI20,PI22
1408 door open jam PI101, PI102, MS101
1488 door open jam PI3,PI9,PI102
1506 stapler jam PI50
1586 stitcher jam SW7,SW5
11A1 feed stationary jam PI18,PI19,PI20
11A2 delivery stationary jam PI11,PI17
11A3 saddle inlet sensor feed stationary jam PI22
Code Type of Sensor Sensor No. / Type of Error
1011 inlet path sensor feed delay jam PI5
1121 inlet path sensor feed stationary jam PI5
1F81 stack delivery jam PI1
1506 staple jam STP
1307 power-on jam POWER ON
1408 door open jam (joint) DOOR
1644 punch hole jam SR2
1347 punch power-on jam LED7/PTR7
Location code/ Location Alarm code/ Description
00 Error code (4 digits) 0246 Failure to write operation.
0247 Failure to write retry operation.
02 Optical System, Reader Unit, Copier 0022 Read motor / delivery motor fan alarm
04 Pick-up/Feeder System, Copier 0008 Optional deck lifter error
0011 Alarm for 1st cassette right deck retry failure
0012 Alarm for 2nd cassette left deck retry failure
0013 Alarm for 3rd cassette retry failure
0014 Alarm for 4th cassette retry failure
0017 Alarm for MF retry failure
0018 Alarm for optional deck retry failure
31 Electrical/ Controller System, Copier 0002 Power supply relay durability alarm
0005 Environment sensor reading alarm
Code Type of Sensor Sensor No. / Type of Error
