Part 3: Adjustment
1.3 Service Mode Adjustment Items
Adjustment
Description
Adjustment Input Mode
Item No.
No specification
PC AV
Component
11 2.3.
Red signal center DC voltage adjustment
●
12 2.3.
Green signal center DC voltage adjustment
●
13 2.3.
Blue signal center DC voltage adjustment
●
14 2.4. Red contrast adjustment ●●●
15 2.4. Green contrast adjustment ●●●
16 2.4. Blue contrast adjustment ●●●
13 2.5. Red signal level adjustment ●●
14 2.5. Green signal level adjustment ●●
15 2.5. Blue signal level adjustment ●●
11 2.8. Contrast linearity adjustment ●●
10 2.7.
White balance (red) adjustment
●●
12 2.7.
White balance (blue) adjustment
●●
19 2.6. Red flicker adjustment ●
20 2.6. Green flicker adjustment ●
21 2.6. Blue flicker adjustment ●
22 2.2. PSIG adjustment ●
23 2.2. PSIG adjustment ●
76 2.1. Fan voltage adjustment ●
94 2.1. Fan voltage adjustment ●
The other adjustment items are not associated with servicing. Do not
change them.
