Canon MP640 - Special Tools; Sensors

1-3. Special Tools
1-4. Sensors
Click on the image to enlarge it.
Name Tool No. Application Remarks
FLOIL KG-107A QY9-0057-000 To the carriage rail sliding portions. In common with the MP610, etc.
No. Sensor Function Possible problems
1 Scanner open sensor Detects opening and closing of the
scanning unit (cover).
- The carriage does not move to the center even when
the scanning unit is opened.
2 FB encoder sensor Detects rotation of the scanner motor,
and controls scanning operation.
- Faulty scanner
- FB motor error
- Faulty scanned or copied images
3 Inner cover sensor Detects opening and closing of the inner
cover.
- The inner cover is open when it should be closed.
- The inner cover is closed when it should be opened.
4 PE sensor Detects the leading and trailing edges of
paper.
- No paper
- Paper jam
5 ASF cam sensor Detects the position of the ASF cam (for
paper feeding from the rear tray).
- ASF cam sensor error
- Paper feeding problem
6 APP encoder sensor Detects rotation of the APP encoder, and
controls paper feeding and purging
operation.
- APP sensor error
- APP position error
7 Carriage encoder
sensor
Detects the position of the carriage. - Carriage position error
- Printing shifts from the correct position.
- Uneven printing
- Strange noise
8 Temperature & Ink
amount sensor
Detects the temperature of the inside of
the machine and the remaining ink
amount.
- Internal temperature error
- Low-ink or out-of-ink warning
9 Ink sensor Detects the position of an ink tank. - Wrong position of an ink tank
- Installation of multiple ink tanks of the same color
- No recognition of an ink tank
10 LF encoder sensor Detects rotation of the LF encoder, and
controls paper feeding.
- LF position error
- Uneven printing
11 Eject encoder sensor Detects rotation of the eject encoder, and
controls paper feeding.
- LF position error
- Uneven printing
12 Valve cam sensor Detects the position of the purge valve
cam, and controls purging operation.
- Valve cam sensor error
13 Pump roller sensor Detects the position of the pump roller,
and controls purging operation.
- Pump roller sensor error
14 Purge cam sensor Detects the position of the purge main
cam, and controls purging operation.
- PG cam sensor error
