8
Components Guide
MV920/MV901/MV900/MV890
0
Left side view
Right side view
Lens cover switch ( 18)
( open, closed)
LCD BACKLIGHT button ( 15)
Speaker ( 28)
CHARGE indicator ( 10)
Terminal cover
switch ( 4)
Grip belt (
14)
AV terminal ( 29)
MIC (microphone) terminal ( 50)
DV terminal ( 63, 65)
Zoom lever ( 22)
Program selector ( 36)
Easy recording
Recording programs
