Canon TS5151 - Removing Jammed Paper from Rear Side

Removing Jammed Paper from Rear Side
Note
• If paper becomes jammed during printing and you need to turn off the printer to remove it, press the
Stop button to stop the printing before you turn off the printer.
1. Rotate printer so that rear side of printer faces toward you.
2.
Open rear tray cover and then pull up paper support.
3.
Detach rear cover.
Pull out the rear cover.
321
