Front View
(1) operation panel
Use to change the settings of the printer or to operate it.
Operation Panel
(2) document cover
Open to load an original on the platen glass.
(3) feed slot cover
Prevents anything from falling into the feed slot.
Open it to slide the paper guides, and close it before printing.
(4) paper support
Extend to load paper in the rear tray.
(5) rear tray cover
Open to load paper in the rear tray.
(6) rear tray
Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same
time, and fed automatically one sheet at a time.
Loading Paper in the Rear Tray
Loading Envelopes
(7) paper guides
Align with both sides of the paper stack.
(8) cassette
Load A4, B5, A5, or Letter-sized plain paper into the cassette, and insert it into the printer.
136
