Settings back side What to enter
[Z offset ({0})] The image is shifted in Z direction (perpendic-
ular on the feed direction) in mm (inches).
A shift > 0 moves the image to the top of the
sheet:
• The distance between the top of the sheet
and the image on the sheet decreases.
• The dots on the verification chart move to
the top of the sheet.
A shift < 0 moves the image to the bottom of
the sheet:
• The distance between the top of the sheet
and the image on the sheet increases.
• The dots on the verification chart move to
the bottom of the sheet.
Ranges
Setting Range (mm) Range (inches)
[X offset ({0})] -5.0 to +5.0 -0.197 to +0.197
[Z offset ({0})] -2.5 to +2.5 -0.098 to +0.098
NOTE
If the shift is too much, the image be printed over the edges of the sheet.
• Risk of reprinting.
• Risk of system pollution.
Trapezoid Shape Image
When to do
The trapezoid shape is perpendicular to the feed direction.
Trapezoid Shape Image
Chapter 13 - Media Handling
335
