MAP1 Page 31 of 31

Installation Manual June 2018 • Rev. 1.6

DOOR OPERATOR OUTPUT – ALL CARDS

The (MF) multifunction relay, when configured as

Door Operator_All

, will be

activated by all cards and by exit button press. The lock relay will be activated first

followed by a one second pulse on this MF relay which is used to trigger the door

operator.

DOOR OPERATOR OUTPUT – HANDICAP CARDS ONLY

The (MF) multifunction relay, when configured as

Door Operator_HC

, will only be

activated by cards designated as handicap and by exit button press. The lock relay will

be activated first followed by a one second pulse on this MF relay which is used to

trigger the door operator.
