1.9 SYSTEM SPECIFICATIONS
Electrical characteristics of the device:
• Supply voltage: 230V~
• Supply voltage type: single-phase alternative current (~).
• Power supply frequency: 50 Hz.
Characteristics of the radiofrequency output signal for each channel:
• Frequency:
- 0,8MHz +/-25%
- 1,0 MHz +/-25%
- 1,2 MHz +/-25%
• Maximum output: 45 W +/-10% for a load of 06-j530 ohms to 1 MHz.
• Maximum output tension for a load of 106-j530 ohms: 345 efficient volts.
• Delivered power control: Double control by pulse width modulator and amplitude
control.
• Control signal (PWM) frequency: 10Hz.
Displayed values
• Delivered energy. Expresed in kilojoules. Tolerance +/-20%.
• Temperature in active accessories. Measurement tolerance of +/-2ºC in the
sensor located on the active accesory
Model
Nº of channels
Dimensions
Weight
Max. Power
consumption
C 400 4 562 mm x 211 mm x 420 mm 22,5 Kg
800VA
C 300 3 562 mm x 211 mm x 420 mm 20,3 Kg
600VA
C 200 2 220 mm x 211 mm x 420 mm 12,9 Kg
400VA
C 100 1 220 mm x 211 mm x 420 mm 10,7 Kg 100VA
C 50 1 220 mm x 211 mm x 420 mm 10,7 Kg 100VA
C 500 1 220 mm x 211 mm x 420 mm 10,7 Kg
100VA
The weight referred to in the table above corresponds exclusively to the CIM console,
without taking into account the accessories or the foot. The foot weighs 20 kilos.
The manufacturer reserves the right to make the necessary estimated changes without
notice.
