User Manual
Page 7 of 95
1.5.- DESCRIPTION OF THE DEVICE
This section describes the C 400 unit, which is the most complete model of the range,
with all the available options described.
The other machines in the CIM range have a similar structure, differing only in the
number of available channels and accessories. See section 1.2 CAPENERGY
equipment Catalog for details.
C 400 is composed of equipment and accessories.
The machine is divided into the following parts:
Front Panel
Back Panel
Front Panel
The front panel contains the user interface and the connections for the different
accessories. See image below:
Figure 1.1. Front panel
1.- SCREEN
2.- SCREEN CONTROL BUTTONS
3.- CHANNEL 1
4.- CHANNEL 2
5.- CHANNEL 3
6.- CHANNEL 4
