Instruction manual C816C
23
Please keep this instruction manual for future reference
ADJUSTING THE BRACKET POSITION
Fix the hob to the work surface by screwing 4 brackets on the bottom of hob (see picture) after
installation. Adjust the bracket position to suit different worktop thickness’s.
oonn
HOB
WORK SURFACE
A
HOB
WORK SURFACE
B
BRACKET
BRACKET
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture). This will
ensure the hob is properly secured to the underside of the work surface.
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop
after installation (see picture). This will ensure the hob is properly secured to the underside of the
work surface.
CAUTIONS:
› The ceramic hob should not be mounted next to cooling equipment, dishwashers
and rotary dryers.
› The wall and cooking zone above the work surface must withstand heat.
› To avoid any damage, the worktop sandwich layer and adhesive must be heat resistant.
