OPERATING THE DOWNDRAFT EXTRACTOR
MODEL DD911
A: Light ON/OFF key
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
function selection
s
How the downdraft works
LIGHT ON/OFF KEY
The light switches on and off only when the carriage is fully OPEN.
Pressing this button with the carriage closed will cause the carriage to open and then the light will
switch on. The button also serves to switch off the light if it is on.
MODEL DD911
B:
ON/OFF key
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
function selection
s
How the downdraft works
ON/OFF KEY
This starts the extraction carriage upward movement and when it is fully open, it sets the second
extraction speed.
With the carriage open: it switches off the motor and if on, the light; then it retracts the extraction
carriage.
MODEL DD911
C:
(-) Key
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
function selection
s
How the downdraft works
(-) KEY
This reduces the speed of the extractor motor from the 4th speed until the motor switches off,
without closing the pull-out carriage.
MODEL DD911
D: Indicators
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
function selection
s
How the downdraft works
INDICATORS
› This signals the speed setting, by only the relevant LED switching on (see ‘Timing’ on pg.18
for further information)
› This signals that all filters have been saturated by all LEDs switching on.
MODEL DD911
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
function selection
s
How the downdraft works
(+) KEY
This increases the speed of the extractor motor, from 1st to 4th speed, without moving the
extractor panel.
MODEL DD911
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
•Thissignalsthatallfiltershavebeensatu
F:
function selection
s
How the downdraft works
TIMER
10 min after setting, it serves to stop the extractor motor, close the carriage and switch the lights
off, if they are on. The set function is signalled by the flashing LED’s “D” for the set speed. The
timer can be cancelled by pressing the key again.
