CaptiveAire D76 - MSC Menu Tree

19
MSC Menu Tree
RANGE: NIDEC, TELCO 42, TELCO 48 (DEFAULT),
ZIEHL, 0-10V, OTHER
BOARD CONFIG
MOTOR TYPE
RANGE: LOCAL (DEFAULT),
REMOTE MODBUS, REMOTE 0-10V
CONTROL TYPE
SPEED SETTING LOW SPEED
RANGE: 20%-100% or 0-10V
DEFAULT: 20% or 0V
HIGH SPEED
RANGE: 20%-100% or 0-10V
DEFAULT: 100% or 10V
SET SPEED %
RANGE: 20%-100% or 0-10V
DEFAULT: VARIES
VOLTAGE RANGE
RANGE: 5V, 10V, 24V
DEFAULT: 24V
RANGE: 11-18 (EXHAUST FAN) / 21 or 22 (SUPPLY FAN)
DEFAULT: 11
MODBUS #
FEEDBACK FAULT
OPTIONS
FACTORY RESTORE?
[ENTER] TO RESTORE
RESTORE SETTINGS
PASSWORD
0000
CHANGE PASSWORD
PASSWORD OK?
0000
SOFTWARE VERSION
FAULTS
CURRENT SOFTWARE VERSION
DISPLAYED
DISPLAYS FAULTS DAY/HOUR/MINUTE/SECONDS
DISPLAYS BOARD REBOOT
FAULT HISTORY
FAULT TOTALS
FEEDBACK, MODBUS, REBOOT, VARIABLE DEVICE,
and TOTAL FAULT COUNTS ARE SHOWN
2 SPEED
ANALOG SPEED
RANGE: 20%-100% or 0-10V
DEFAULT: VARIES
ENABLED/DISABLED/CALIBRATION
ENABLED/DISABLED
DEFAULT: DISABLED
CLEAR FAULTS
CLEAR FAULTS?
[ENTER] TO CLEAR
IO STATUS
DISPLAYS INCOMING VOLTAGE (0-10V) TO THE MSC.
V IN
V OUT
RPM
DISPLAYS MOTOR RPM FEEDBACK. ZIEHL MOTORS
DO NOT PROVIDE FEEDBACK
PWM V
DISPLAYS EQUIVALENT VOLTAGE READING OF THE
PWM OUTPUT TO THE MOTOR.
SPEED %
DISPLAYS PWM PERCENTAGE OUTPUT VALUE TO
THE MOTOR.
DISPLAYS OUTPUT VOLTAGE (0-10 V) TO THE
MOTOR.
INPUT THRESHOLD
ZERO OPERATION
THRESHOLD
RANGE: OFF - LOW SPEED
DEFAULT: LOW SPEED
RANGE: 0-10V
DEFAULT: 0V
SERVICE
SAVE T & B
T & B SAVE?
[ENTER] TO SAVE
FACTORY SETTINGS
T & B SETTINGS
T & B RESTORE?
[ENTER] TO RESTORE
