ACTECH SMV VFD
Table 6 - Cross Reference
HP Part Number Volts
1Ø
Input
3Ø
Input
Input Amps 1Ø
120V AC
Input Amps 1Ø
240V AC
Output
Amps
Breaker 1Ø
120V AC
Breaker 1Ø
240V AC
0.5 ESV371N01SXB 120/240V X - 9.2 4.6 2.4 15 15
1 ESV751N01SXB 120/240V X - 16.6 8.3 4.2 25 15
1.5 ESV112N01SXB 120/240V X - 20 10 6 30 20
HP Part Number Volts
1Ø
Input
3Ø
Input
Input Amps 1Ø Input Amps 3Ø
Output
Amps
Breaker 1Ø Breaker 3Ø
0.5 ESV371N02YXB 240V X X 5.1 2.9 2.4 15 15
1 ESV751N02YXB 240V X X 8.8 5 4.2 15 15
1.5 ESV112N02YXB 240V X X 12 6.9 6 20 15
2 ESV152N02YXB 240V X X 13.3 8.1 7 25 15
3 ESV222N02YXB 240V X X 17.1 10.8 9.6 30 20
5 ESV402N02TXB 240V - X - 18.6 16.5 - 30
7.5 ESV552N02TXB 240V - X - 26 23 - 40
10 ESV752N02TXB 240V - X - 33 29 - 50
15 ESV113N02TXB 240V - X - 48 42 - 80
20 ESV153N02TXB 240V - X - 59 54 - 90
1 ESV751N04TXB 480V - X - 2.5 2.1 - 15
1.5 ESV112N04TXB 480V - X - 3.6 3 - 15
2 ESV152N04TXB 480V - X - 4.1 3.5 - 15
3 ESV222N04TXB 480V - X - 5.4 4.8 - 15
5 ESV402N04TXB 480V - X - 9.3 8.2 - 15
7.5 ESV552N04TXB 480V - X - 12.4 11 - 20
10 ESV752N04TXB 480V - X - 15.8 14 - 25
15 ESV113N04TXB 480V - X - 24 21 - 40
20 ESV153N04TXB 480V - X - 31 27 - 50
25 ESV183N04TXB 480V - X - 38 34 - 70
30 ESV223N04TXB 480V - X - 45 40 - 80
40 ESV303N04TXB 480V - X - 59 52 - 100
50 ESV373N04TXB 480V - X - 74 65 - 125
60 ESV453N04TXB 480V - X - 87 77 - 150
1 ESV751N06TXB 600V - X - 2 1.7 - 15
2 ESV152N06TXB 600V - X - 3.2 2.7 - 15
3 ESV222N06TXB 600V - X - 4.4 3.9 - 15
5 ESV402N06TXB 600V - X - 6.8 6.1 - 15
7.5 ESV552N06TXB 600V - X - 10.2 9 - 20
10 ESV752N06TXB 600V - X - 12.4 11 - 20
15 ESV113N06TXB 600V - X - 19.7 17 - 30
20 ESV153N06TXB 600V - X - 25 22 - 40
25 ESV183N06TXB 600V - X - 31 27 - 50
30 ESV223N06TXB 600V - X - 36 32 - 60
40 ESV303N06TXB 600V - X - 47 41 - 70
50 ESV373N06TXB 600V - X - 59 52 - 90
60 ESV453N06TXB 600V - X - 71 62 - 110
