Reset Overview
There are multiple actions required to reset the fire system. The following must be completed by a
Certified Fire System Technician.
1. The duct firestat must be cooled below its internal set point.
2. The remote manual actuation device (push/pull station) must be reset by twisting the button clockwise
until it resets.
3. Press the “Push To Reset Fire System” button.
4. Reset the pneumatic actuators (PKA, SVA), refer to “Disconnecting Service Tank/Re-arming
System” on page 62.
Note: The firestat must be cool, and the remote manual actuation device (push/pull station) must
be reset for this button to work.
The fire system must be re-commissioned per the manufacturer’s recommendations and guidelines by an
authorized fire system distributor and/or authorized service agent.
After a fire, full inspection by a certified professional must be conducted prior to restarting the fire system.
Figure 45 - Fire System Reset
1. LED Indicator
2. Alarm Speaker
3. Panel Latch
4. Reset Button
5. Test Mode/Fire System Armed
Switch
