59
Typical DIP Switch Arrangement
Only One Fire Protection System Panel on the network:
Two Fire Protection System (or CORE) Panels on the network:
Two Fire Protection System (or CORE) Panels on the network:
Three Fire Protection System (or CORE) Panels on the network:
Four Fire Protection System (or CORE) Panels on the network:
For additional configurations, refer to Table 21 for the electrical board (PCBCORE) DIP switch settings.
The configurations above are shown with all electrical boards (PCBCORE) in the same Fire Group and
may be configured differently, even if the control panels are on the same network. Every panel with
matching fire group settings (DIP switches 6 and 7) will activate simultaneously in a fire condition.
Core Board # DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
#1 (Hood Master) Closed Open Open Open Closed Open Open Closed
Core Board # DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
#1 (2nd Hood Slave) Closed Open Open Open Open Open Open Closed
#2 (Hood Master) Open Closed Open Open Closed Open Open Closed
Core Board # DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
#1 (PCU Slave) Closed Open Open Open Open Open Open Closed
#2 (Hood Master) Open Closed Open Open Closed Open Open Closed
Core Board # DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
#1 (2nd Hood Slave) Closed Open Open Open Open Open Open Closed
#2 (PCU Slave) Open Closed Open Open Open Open Open Open
#3 (Hood Master) Closed Closed Open Open Closed Open Open Closed
Core Board # DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
#1 (2nd Hood Slave) Closed Open Open Open Open Open Open Closed
#2 (PCU Slave) Open Closed Open Open Open Open Open Open
#3 (2nd PCU Slave) Closed Closed Open Open Open Open Open Open
#4 (Hood Master) Open Open Closed Open Closed Open Open Closed
