EWC SUPPRESSION SYSTEM PARTS
Table 24 - System Components
Description Part Number A/X Number
EWC Cylinder Assembly, Filled & Pressurized
87-300001-001 A0030114
Bracket, EWC Cylinder EWC-UCTANKBRACKET N/A
Discharge Adapter WK-283952-000 A0030115
O-Ring for Discharge Adapter WK-108019-000 A0030738
Vent Plug, Distribution Piping 60-9196984-000 A0030116
ADP Appliance Nozzle with Foil Seal Cap 87-300020-001 A0030117
TF1 Total Flood Nozzle with Foil Seal Cap 87-300021-001 A0030118
R Appliance Nozzle with Foil Seal Cap 87-120019-001 A0032708
Nozzle Swivel Adapter 87-120021-001 A0030119
Primary Actuator Kit (PAK) 87-300030-001 A0030120
Primary Actuator Solenoid Valve, 24VDC 87-300031-001 A0030121
Secondary Valve Actuator (SVA) 87-120042-001 A0030124
Secondary Valve Actuator Hose 7” 87-120045-001 A0031516
Secondary Valve Actuator Hose 24” 87-120045-002 A0030125
Secondary Valve Actuator Hose 60” 87-120045-003 A0031517
Cylinder Supervisory Pressure Switch 87-300040-001 A0030126
Gas Shut-off Valve, 3/4” (ASCO) 8214235 A0024941
Gas Shut-off Valve, 1” (ASCO) 8214250 A0024937
Gas Shut-off Valve, 1-1/4” (ASCO) 8214265 A0024938
Gas Shut-off Valve, 1-1/2” (ASCO) 8214275 A0024939
Gas Shut-off Valve, 2” (ASCO) 8214280 A0024940
Gas Shut-off Valve, 2-1/2” (ASCO) 8214290 A0024936
Gas Shut-off Valve, 3” (ASCO) 8214240 A0024935
Table 25 - Maintenance & Recharge
Description Part Number A/X Number
Valve Protection Plate WK-255096-000 A0030739
Anti-Recoil Plate WK-255681-000 A0030740
EWC Valve Rebuild Kit
87-120067-001 A0030741
Wet Chemical Recharge, single EWC cylinder 87-300101-001 A0030127
Discharge Adapter Kit (includes mounting flange) 83-844908-000 N/A
Replacement Nozzle Cap 60-9197290-000 A0030128
Replacement Nozzle Seals 60-9197054-000 A0030129
Schrader Cap 87-300140-001 A0030130
Schrader Valve 87-300141-001 A0030515
SVA bolts 87-300152-001 A0030131
Table 26 - Service Parts (not supplied with system)
Description Part Number A/X Number
Low-Loss Fitting 1/4” Male to Male Thread Union U24 A0030896
Low-Loss Fitting 1/4” Straight Adapter Male to Female Thread NABS A0030898
1/4” Refrigerant Test Hose, 30" Long, Low-Loss Fittings NHD1430 A0030899
1/4” Refrigerant Test Hose, 60" Long, Low-Loss Fittings NHD1460 A0030900
Nitrogen Tank HP20 A0030901
Pressure Regulator GEN450F A0030902
