18
5. OPERATING YOUR SCOOTER
5.3 FIXED HOOKS
» To ensure safety during the transportation.
There are four xed hooks for xing scooter on
other vehicles.
» Make sure the scooter is in D position when
transporting. (Figure 29)
» Do not sit on the scooter during transportation.
Figure 29
5.4 DISASSEMBLING YOUR SCOOTER
Disassembling seat:
» By lifting lever to remove seat upwards. (Figure 30)
Rear Compartment cover:
» Open the compartment cover upwards according to the example. (Figure 31)
Disassembling front basket:
» Lift the front basket upwards. (Figure 32)
Figure 30 Figure 31 Figure 32
Free wheel operation is only recommended on at
surfaces. Never leave your scooter on gradient with
its motors disengaged. When adjusting N-D lever,
do not sit on the scooter.
It’s not able to drive the scooter when the lever is
in Neutral. Turn o the scooter and switch to D
position, then turn on and drive scooter.
Figure 28
