28
11.TECHNICAL SPECIFICATIONS
Overall Length 1400 mm / 55.1”
Overall Width 680 mm / 26.8”
Overall Height 1325 mm / 52.2”
Front Wheels 330 mm / 13”
Rear Wheels 330 mm / 13”
Weight W/ Batteries 144 kg / 317 Ibs
Max. Speed 12.8 kmph / 8 mph
Weight Capacity 160 kg / 352.7 Ibs
Ground Clearance 90 mm / 3.5”
Grade Climbable 10 degree
Curb Climbable 50 mm / 2”
Turning Radius 1660 mm / 65.4”
Suspension Front & Rear
Brake Hand Brake & Electro-Mechanical
Seat Type
Swivel Captain Seat With Seat Sliding
Mechanism & Back Angle Adjustment
Seat Width 515 mm / 20.3”
Motor Size 850W, 5000 r.p.m.
Battery Size (2) 12V. 75Ah
Battery Weight 52 kg / 115 lbs
Travel Range 48 km / 30 Miles (without load)
Battery Charger 8A O Board
Electronics
On / O Key Switch, Battery Level
Indicator, Speed Control Knob
*Subject to change without notice. ( Rev. 2, 2018/11/20 )
