FCM electronic regulator - Preliminary version Cod. +302235300 - Rel. 2.0 del 30/11/98
27
9 Table of Parameters
Parameter Min Max Def U.M. Nuovi
PASSWORD
77 -
PARAMETERS CONCERNING THE SET-POINT
St1
(*) Set-point 1 (main) -40
0.0
100
100
0.0 °C
r.H./bar
St2 (*) Set-point 2 (secondary) - parameter accessible only if C00=5, 6, 7, 8
-40
0.0
100
100
0.0 °C
r.H./bar
C00
Operating mode:
0= Slave direct
1= Slave reverse
2= Direct
3= Reverse
4= Dir. & Rev. (from input ID1)
5= Dir-St1 & Dir-St2 (from input ID1)
6= Rev-St1 & Rev -St2 (from input ID1)
7= Dir-St1 & Rev-St2 (from input ID1)
8= Dir.-St1 & Rev-St2-Defrost (from ID1)
0 8 2 -
P01
(*) Differential of St1 0.0 100 2.0 °C/r.H./bar
P02 (*) Differential of St2 - parameter accessible only if C00=5, 6, 7, 8
0.0 100 2.0 °C/r.H./bar
C03
(*) Type of Set-point
0=Set-point corresponding to the min. output value
1=Set-point corresponding to the average output value
2=Set-point corresponding to the max. output value
0 2 0 -
ANALOGUE OUTPUT
C04
Min. output value 0 C05 0 %
C05
Max. output value C04 100 100 %
C06
Soft-start 0 120 2 s
C07
(*) Cut-off 0.0 100 0.0 -
C08
(*) Speed-up 0 120 0 s
C09
(*) Integral action 0 999 0 s
C10
Output value with disconnected probe or High alarm
0=discon. probe: disabled out. (0%), High(Low) alarm: normal output
1=discon. probe: output at C04 (min value), High(Low) alarm: normal output
2=discon. probe: out. at C05 (max value), High(Low) alarm: normal output
3=discon. probe: disabled out. (0%), High(Low) alarm: out. at 100%
4=discon. probe: out. at C04 (min value), High(Low) alarm: out. at 100%
5=discon. probe: out. at C05 (max value), High(Low) alarm: out. at 100%
0 5 0 -
