9.3 ir33+ part numbers
Features
IREVM00* IREVM0E* IREVS0* IREVS0L* IREVS0E* IREVY0* IREVY0L* IREVY0E* IREVC00* IREVC*L* IREVC*H* IREVF*E*
Power supply
12Vac/Vdc (-15/+10%), 50/60 Hz
  
12/24 Vac (-15/+10%), 50/60 Hz
 
230 Vac (-15/+10%), 50/60 Hz
 
115/230 Vac (-15/+10%), 50/60 Hz

Power consumption 4 VA 3 VA 4 VA 4 VA 3 VA 4 VA 4 VA 4 VA 4 VA 4 VA 6 VA 3 VA
Precision
Standard Carel NTC: -50T50°C
-50T90°C
1°C
3°C
High temperature NTC: -20T115°C 1.5°C (outside this range 4°C)
Standard Carel PTC: -50T50°C
-50T150°C
2°C
4°C
Control / defrost / product probe
Standard Carel NTC (10 kΩ at 25°C), -50T90°C

High temp. NTC (50 kΩ at 25°C), -40T150°C

PTC (985 kΩ at 0°C), -50T150°C Only on IR33*7* models
User interface
display 3 digit LED plus icons
Keypad ergonomic 4-button
Outputs
compressor 8 A, 16 A, 2 HP 16 A, 2 HP 16 A, 2 HP 8 A, 2 HP
defrost 16 A, 8 A 8 A 8 A
fan 8 A 5 A
aux/light 8 A on model IR33S0EA* 5A on model IRYS0EP* 8 A
Programming
keypad

key

Special functions
HACCP/ Real Time Clock Function can be enabled when Real Time Clock option available, models: IR*(C,B,L,T,S,U,Y,Z)*
and on IR33 power models: IR*(E,F.0,W)*
Buzzer

repeater display standard for models with 12 Vac, 12/24 Vac, 115/230 Vac power supply. Important: models
with 230 Vac or 115 Vac power supply (internal transformer) do not support the repeater
display
decimal point

Carel network serial interface

Other
Quality and precision: in-circuit testing

UL marking

VDE marking

EN 13485 (thermometer standard)

Note: = standard
Relay rating to EN60730-1: 8 A, 8(4)A 16 A, 12(2) A 2 HP, 10(10) A (*) up to 60°C ambient temperature
Tab. 9.c
9.4 ir33+ power part numbers
Features IREV0EHA0 IREVY0EHA0 IREVF0EHA0 IREVF0EFA0
Power supply 230 Vac
Outputs
compressor 2 HP, 12(10)A
defrost 8 A 8 A 8 A
evaporator fans 5 A 5 A
Inputs
room temperature

defrost temperature

digital input/probe 3

Pluses
HACCP

programming key

high e ciency display

buzzer

real time clock

RS485 option

Relay rating to EN60703-1: 8 A, 8(4) A; 16 A, 12(2) A; 2 HP, 10(10) A
Tab. 9.d
