9.5 ir33+ wide part numbers
Features PBEVY0EVLG PBEVC0HNLG PBEVH0HNHG PBEVH0HNHW PBEVC0SNNG PBEVC0SNNW
Power supply
230 Vac, (-15/+10%), 50/60 Hz

115/230 Vac, (-15/+10%), 50/60 Hz

 (small)  (small)
Precision
Standard Carel NTC: -50T50°C
-50T90°C
1°C
3°C
High temperature NTC -40T-20°C
-50T115°C
115T150°C
4°C
1.5 °C
4° C
Standard Carel PTC -50T50°C
(only on IREV*7* models) 50T150°C
2°C
4°C
User interface (display (3 digit LED plus icons)) green white green white
Keypad ergonomic 8-button
Outputs
compressor 16 A 2 HP 2 HP 2 HP 30 A 30 A
defrost 8 A 16 A 16 A 16 A 8 A 8 A
evaporator fan 8 A 8 A 8 A 5 A 5 A
aux1 8 A 8 A 8 A 8 A 5 A 5 A
aux2 8 A 8 A
Programming
keypad and key

Special functions
HACCP/ Real Time Clock Function can be enabled when Real Time Clock available (models: PBEV*(C, L, S, Y)*)
buzzer

repeater display

For models with 12 Vac, 12/24 Vac, 115/230 Vac power supply. The models with
internal transformer (115 Vac or 230 Vac) do not support the repeater display
decimal point

CAREL serial network interface

Note: = standard
Tab. 9.e
9.6 easy wide part numbers
Features
PBEVS0EAAA PBEVY0EVD0 PBEVC0HND0 PBEVC0HNBA PBEVC0HCAA PBEVH0HNAA PBEVH0HNB0 PBEVH0HNBW PBEVS0SAFA PBEVC0SNFA PBEVC0SNFW
Power supply
230 Vac (-15/+10%), 50/60 Hz

115/230 Vac (-15/+10%), 50/60 Hz

small small small
Precision
Standard Carel NTC: -50T50°C
-50T90°C
1°C
3°C
High temperature NTC -40T-20
-20T115°C
115T150 °C
4°C
1.5 °C
4°C
Standard Carel PTC -50T50°C
(only on PBEV*7* models): -50T150°C
2°C
4°C
User interface
Display (3 digit LED plus icons) blue red red blue blue blue red white blue blue white
Keypad ergonomic 4-button
Outputs
compressor 8 A 16 A 2 HP 2 HP 2 HP 2 HP 2 HP 2 HP 30 A 30 A 30 A
defrost 8 A 16 A 16 A 16 A 16 A 16 A 16 A 8 A 8 A
evaporator fan 8 A 8 A 8 A 8 A 8 A 8 A 5 A 5 A
aux1 8 A 8 A 8 A 8 A 8 A 8 A 8 A 8 A 8 A 5 A 5 A
aux2 8 A 8 A 8 A
Programming
keypad

key

Special functions
HACCP/ Real Time Clock Function can be enabled when Real Time Clock available
Models: PBEV*(C,L,S,Y)*
buzzer

repeater display standard for models with 12 Vac, 12/24 Vac, 115/230 Vac power supply. The models with inter-
nal transformer (115 Vac or 230 Vac) do not support the repeater display
decimal point

Carel network serial interface

Note:  = standard
Tab. 9.f
