Carel µC2 User Manual

83
µC
2
- cod. +030220420 - rel. 2.0 - 18.10.04
montaggio a pannello
panel mounting
montaggio su guida din
din rail mounting
S
e
l
P
R
G
c
o
m
p
x
1
0
0
dima di foratura
drilling template
71x29mm
fissaggio/ overall dimensions 91.5x36.5mm
33
110
75 64
70 60
74
Fig. 8.1
110
70
60
Expansion board
Expansion board
montaggio su guida din
din rail mounting
88
44
36 60
11
Fig. 8.2 Fig. 8.3
Moduli CONVONOFF0 e CONV0/10 A
CONVONOFF0 and CONV0/10 A modules
156
67
18
30
82
82
31
134
Ø 4
34.5
dima di foratura
drilling template
127x69 mm
Ø 4
125
83,5
MCH200TP* versione da pannello
MCH200TP* panel mounting version
Fig. 8.4
Scheda espansione per µC
2
Expansion board for µC
2
MCH200000* µC
2
versione da pannello
MCH200000* µC
2
panel mounting version
MCH200001* µC
2
versione guida din
MCH200001* µC
2
din-rail mounting version
MCH200TW* versione a muro
MCH200TW* wall version
