Fig.2.q
Master/Slave network with user terminals, remote display and external driver.
The Master controller, connected to the supervisor network, coordinates the operation of up to 9 Slave
controllers connected to the network via RS485 Fieldbus. Each controller can be connected to a remote
display or an external driver.
