6.1
Parameter table
Code Description Def Min Max UOM User
User
terminal
Analogue inputs
/P1
Type of probe, group 1 (S1, S2, S3)
0 = PT1000 Standard Range –50T150 °C
1 = NTC Standard Range –50T90°C
1 0 1 - S NO
/P2
Type of probe, group 2 (S4, S5)
1 = NTC Standard Range –50T90°C
2 = 0-5 V
3 = 4-20 mA
2 1 3 - S NO
/P3
Type of probe, group 3 (S6)
0 = PT1000 Standard Range –50T150 °C
1 = NTC Standard Range –50T90°C
2 = 0-5 V
3 = 4-20mA
4 = 0-10V
2 0 4 - S NO
/FA
Assign air off temp. probe (Sm)
0 = Function disabled 6 = Probe S6
1 = Probe S1 -1 = Serial probe S11
2 = Probe S2 -2 = Serial probe S12
3 = Probe S3 -3 = Serial probe S13
4 = Probe S4 -4 = Serial probe S14
5 = Probe S5
1 -4 6 - S NO
/Fb Assign defrost temperature probe (Sd) - see /FA 2 -4 6 - S NO
/Fc Assign air on temperature probe (Sr) - see /FA 3 -4 6 - S NO
/Fd Assign superheated gas temperature probe (tGS) - see /FA 0 -4 6 - S NO
/FE Assign saturated evaporation pressure/temperature probe (PEu/tEu) - see /FA 0 -4 6 - S NO
/FF Assign defrost temperature probe 2 (Sd2) - see /FA 0 -4 6 - S NO
/FG Assign auxiliary temperature probe 1 (Saux1) - see /FA 0 -4 6 - S NO
/FH Assign auxiliary temperature probe 2 (Saux2) - see /FA 0 -4 6 - S NO
/FI Assign ambient temperature probe (SA) - see /FA 0 -4 6 - S NO
/FL Assign ambient humidity probe (SU) - see /FA 0 -4 6 - S NO
/FM Assign glass temperature probe (Svt) - see /FA 0 -4 6 - S NO
/Fn Assign dewpoint value (SdP) - see /FA 0 -4 6 - S NO
/cA Air off temp. probe (Sm) calibration 0 -20 20 °C/°F S NO
/cb Defrost temp. probe (Sd) calibration 0 -20 20 °C/°F S NO
/cc Air on temp. probe (Sr) calibration 0 -20 20 °C/°F S NO
/cd Superheated gas temperature probe (tGs) calibration 0 -20 20 °C/°F M NO
/cE Saturated evaporation pressure probe (PEu) calibration 0 -20 20 °C/°F M NO
/cF Defrost temp. probe 2 (Sd2) calibration 0 -20 20 °C/°F S NO
/cG Auxiliary temperature probe 1 (Saux1) calibration 0 -20 20 °C/°F M NO
/cH Auxiliary temperature probe 2 (Saux2) calibration 0 -20 20 °C/°F M NO
/cI Ambient temp. probe (SA) calibration 0 -20 20 °C/°F S NO
/cL Ambient humidity probe (SU) calibration 0 -20 20 °C/°F S NO
/cM Glass temperature probe (Svt) calibration 0 -20 20 °C/°F S NO
/cn Dewpoint value (SdP) calibration 0 -20 20 °C/°F S NO
/co Saturated evaporation temperature (tEu) calibration 0 -20 20 °C/°F M NO
/UE Maximum value for saturated evap. pressure/temp. probe (PEu/tEu) 9.3 /LE 200 °C/°F M NO
/LE Minimum value for saturated evap. pressure/temp. probe (PEu/tEu) 0 -1 /UE °C/°F M NO
/UL Maximum value for ambient humidity probe (SU) 100 /LL 100 %rH M NO
/LL Minimum value for ambient humidity probe (SU) 0 0 /UL %rH M NO
