ENG

Code Description Def Min Max UOM User

User

terminal

/2 Analogue probe measurement stability 4 1 15 - M NO

Digital inputs

DIA

Assign immediate external alarm digital input

0 = Function disabled 4 = digital input 4 (ID4)

1 = digital input 1 (ID1) 5 = digital input 5 (ID5)

2 = digital input 2 (ID2) -1 = digital input seriale

3 = digital input 3 (ID3)

0 -1 5 - S NO

DIb Assign delayed external alarm digital input - see DIA 0 -1 5 - S NO

DIc Assign enable defrost digital input - see DIA 0 -1 5 - S NO

DId Assign start defrost digital input - see DIA 0 -1 5 - S NO

DIE Assign door switch with solenoid/comp. and evap. fans OFF digital input - see DIA 0 -1 5 - S NO

DIF Assign remote ON/OFF digital input - see DIA 0 -1 5 - S NO

DIG Assign curtain switch digital input - see DIA 0 -1 5 - S NO

DIH Assign start/stop continuous cycle digital input - see DIA 0 -1 5 - S NO

DII Assign input status monitoring digital input - see DIA 0 -1 5 - S NO

DIL Assign timed digital input - see DIA 0 -1 5 - S NO

DIM Assign Standby mode switch digital input - see DIA 0 -1 5 - S NO

DIn Assign Clean mode switch digital input - see DIA 0 -1 5 - S NO

DIo Assign working parameters set change digital input - see DIA 0 -1 5 - S NO

DIP Assign door switch without control stop digital input - see DIA 0 -1 5 - S NO

DIr Assign defrost according to DI status digital input - see DIA 0 -1 5 - S NO

rIA

Immediate external alarm digital input logic

0 = direct logic

1 = reverse logic

0 0 1 - S NO

rIb Delayed external alarm digital input logic - see rIA 0 0 1 - S NO

rIc Enable defrost digital input logic - see rIA 0 0 1 - S NO

rId Start defrost digital input logic - see rIA 0 0 1 - S NO

rIE Door switch with /solenoid comp. and fans OFF digital input logic - see rIA 0 0 1 - S NO

rIF Remote ON/OFF digital input logic - see rIA 0 0 1 - S NO

rIG Curtain switch digital input logic - see rIA 0 0 1 - S NO

RiH Start/stop continuous cycle digital input logic - see rIA 0 0 1 - S NO

rII Input status monitoring digital input logic - see rIA 0 0 1 - S NO

rIL Timed digital input logic - see rIA 0 0 1 - S NO

rIM Standby mode switch digital input logic - see rIA 0 0 1 - S NO

rIn Clean mode switch digital input logic - see rIA 0 0 1 - S NO

rIo Change working parameter configuration digital input logic - see rIA 0 0 1 - S NO

rIP Door switch without control stop digital input - see rIA 0 0 1 - S NO

rIr Defrost according to DI status digital input logic - see rIA 0 0 1 - S NO

Select digital input broadcast from Master to Slaves (only on Master)

0 = from supervisor 3 =Digital input 3 (ID3)

1 = Digital input 1 (ID1) 4 = Digital input 4 (ID4)

2 = Digital input 2 (ID2) 5 = Digital input 5 (ID5)

0 0 5 - S NO

dIt

Timer duration (timed input)

0 = function disabled

0 0 999 min S NO

Digital outputs

DOA

Assign solenoid/comp. digital output

0 = not set 3 = digital output 3 (NO3)

1 = digital output 1 (NO1) 4 = digital output 4 (NO4)

2 = digital output 2 (NO2)

3 0 4 - S NO

DOb Assign alarm digital output - see DOA 0 0 4 - S NO

DOc Assign auxiliary digital output - see DOA 0 0 4 - S NO

DOd Assign auxiliary serving the Master on the Slaves digital output - see DOA 0 0 4 - S NO

DOE Assign light digital output - see DOA 4 0 4 - S NO

DOF Assign light serving the Master on the Slaves digital output - see DOA 0 0 4 - S NO

86|6. Parameter table

MPXone +0300086EN rel. 1.0– 04.09.2018
