In the screens that feature modifiable fields, the ↵ button selects the various fields in sequence, in this case the screens can be
scrolled again only when the cursor returns to the top left position. When the cursor is in a field, the arrow buttons ⇑, ⇓ increase
or decrease the current numbers or characters (strings) while the horizontal arrows ⇐,⇒ move the cursors to the adjacent
characters. In a numeric field, increasing from the number 9 increases the next highest digit.
Inside a field, pressing the Esc button resets the value prior to the modification.
 'LVSOD\VFUHHQ
On start-up, PlantWatch displays the main screen that summarises the status of the instruments, the status of PlantWatch itself,
and the current date and time. From this screen, the arrow buttons can be used to scroll the display of the instrument variables
and to access the menus. These can display the log of the events/alarms, activate manual prints and access the ,QIR menu. 
Variables, instrument n-1
ÆÇ
Variables, instrument 2
ÆÇ
Variables, instrument 1
ÆÇ
Main screen
ÆÇ
Display Event log
>All
>Only active
⇒
Date
Instrument name
Description
ÆÇ
Print menu
>Print events
>Printing variables log
>Print current values
⇒
Print commands
ÆÇ
Cancel print
ÆÇ
Info
>Logs
>GSM
>Software version
⇒
Information screens
ÆÇ
Variables, instrument n
ÆÇ
