 'DWDSURFHVVLQJFHQWUHFRQILJXUDWLRQ
The parameters that need to be set are the overall enabling of the calls, and the telephone number of the centre.
The “Test call” field allows test calls to be made. Before making such calls, the configuration must be saved so that the
parameters displayed coincide with those that are operative.
The calls to the centre can be made to notify alarms and to download the log. Both functions can be enabled separately.
The “Password” and “User” fields must be set to coincide with those of the MasterPlant or the “PlantWatch manager”
configuration program. The right to access these are initially (default values) set to the maximum (all remote operations are
accepted). Subsequently, the user may restrict the allowed actions using the configuration program.
 )D[FRQILJXUDWLRQ
The parameters that need to be set are the enabling of the calls and the fax numbers to be called.
Depending on the letter that appears in the right-hand field, the calls to the second (B) and third (C) fax
number may be conditioned by the outcome of the transmission to the previous number, that is, C by B
and B by A.
,QGLFDWLRQ LQ WKH ULJKWKDQG
ILHOG
$FWLRQ
- call disabled
A B C (capital letter) call enabled in forced mode to numbers A, B, C
b c (small letter) call enabled but conditioned by the outcome of the calls to numbers A or B
The screen following the previous allows a test call to be made to one of the fax recipients, A, B or C.
Before making such calls, the configuration must be saved so that the parameters displayed coincide with those that are
operative.
 *60PRGHPFRQILJXUDWLRQ
If the modem connected is a GSM cellphone modem, the PIN (Personal Identity Number) can be configured. The PIN is sent to
the modem only if the SIM installed requires this, and so, if the PIN is disabled, this parameter may have any value.
If this parameter is set incorrectly, PlantWatch sends the PIN only once and then generates the “PIN Error” alarm event. In the
event where PlantWatch is shut-down and re-started, the PIN will be sent again: only 3 attempts are allowed, after which the SIM
will need to be removed and, using a cellphone, unlocked using the PUK
 606FRQILJXUDWLRQ
GSM modem
To enable the sending of SMS messages using a cellphone modem, the number of the service centre of the mobile network
operator supplying the SIM card must be entered. This number must be preceded by the international dialling code (+39 for
Italy). If this number is made up of spaces only, it will not be sent to the modem, and the number present in the SIM will be used,
if already entered or pre-configured by the network operator.
PSTN modem
To allow the transmission of SMS messages by 3671 modem, the number of the service centre of a mobile network operator that
supports the UCP/TAP standard must be entered. This number is dialled by the modem to connect to the centre. Also see the
paragraph 6HQG606XVLQJWKHWHOHSKRQHOLQH3671PRGHP
The screen P must be accessed to set the parameters Password (3DVV), %DXG, 3DULW\, %LWV and protocol (UCP/TAP), as
recommended by the service provider. In particular, the values of 3DULW\ %LWV and SURWRFRO W\SHmust be followed, as if wrong no
connection will be possible. The Password is only used by the TAP protocol, it should be entered only if the service centre
allows password-protected login, and should normally be left blank.
The sending of the SMS messages can also be enabled or disabled using the corresponding flag on screen P.
Fax configuration
A:04371234567
b:0123456789
c:0123456789
