3ODQW:DWFK
Cod. Carel. +030221221 – rel. 1.0 dated 20/02/01
3
,1752'8&7,21
PlantWatch is an electronic microprocessor-based device that performs the task of supervising a network of Carel instruments. It
manages and records the alarms and the logs of the main values controlled, allowing the data to be transferred via modem to a
service centre. It can also transmit the alarms by fax or SMS and print automatic reports.
Its main use is for the supervision of small and medium-sized supermarkets.
PlantWatch LVQRW a stand-alone DataLogger: it is not fitted with its own probes, but rather reads the values measured by the other
instruments connected to it.
*HQHUDOFKDUDFWHULVWLFV
PlantWatch, while featuring functions that can normally be obtained only using a personal computer, is extremely compact and
easy to use. It is a completely independent device, in that its operation does not require the installation of any external device or
software; its own keypad and display allow the fundamental parameters to be set.
Even greater flexibility can be obtained using the options available for the PlantWatch line. The remote connection, fax, SMS
and data centre connection features are available only when PlantWatch is fitted with a modem. There are two possible solutions
in this case: order the version with internal modem, PLW00M0000, or alternatively connect an external PSTN or GSM modem,
using the PLW0PMD000 adapter.
Using the RS485-Printer adapter, PlantWatch can be connected to a parallel printer, which can be located at any point of the
RS485 network that connects PlantWatch to the Carel instruments. The RS485-Printer adapter also performs the function of
network watch-dog.
&RGHV
codes description
PLW00B0000 Basic version, an external modem may be connected to the RS232 port using an 8-way telephone connector -
DB25 male adapter (kit PLW0PMD000), power supply 230V.
PLW00U0000 As per the PLW00B0000, yet with 115V power supply.
PLW00M0000 Version fitted with internal 33.6 PSTN modem. Power supply 230V
PLW0PPC000 Kit for RS 232 direct serial connection to a personal computer. The kit is made up of a 5-metre, 8-way flat
telephone cable, an RJ45-DB9 female adapter with DCE connections for direct fitting to the PC’s serial port,
and the ³3ODQW:DWFKPDQDJHU´ configuration software.
PLW0PMD000 Kit for the connection of an external modem. It contains a 5-metre, 8-way flat telephone cable, an RJ45-DB25
male adapter with DTE connections for direct fitting to the female connector on the modem.
PLWOPPRT00 Parallel printer adapter module for the Carel RS485 network, desk-top version complete with 230V power
plug.
PLWOPPRD00 Parallel printer adapter module for the Carel RS485 network, DIN rail version.
Table. 2.1
All the versions feature an RS232 port on the 8-way telephone connector, which is permanently accessible through the channel
(maximum length 10m) or alternatively by removing the front panel for the initial configuration or downloading the data logs.
The connection to the PC is made using a cable adapter from the telephone connector to a DB9 female connector.
All the versions feature the management of a Centronics parallel printer using an optional module connected to the RS485
peripherals network (PLWOPPRT00/ PLWOPPRD00)
