Carel PlantWatch

3ODQW:DWFK
Cod. Carel. +030221221 – rel. 1.0 dated 20/02/01
34
 606UHFLSLHQWV
Up to 3 numbers can be entered as recipients of the SMS messages; next to each number is a flag to enable or disable the send.
As in the FAX screen, these have the values A, B, C for enabling or disabling the call.
The SMS is sent at the same time and in unconditioned mode to all the enabled numbers.
The messages are considered as having been transmitted when the network operator accepts the message; the effective delivery
to the recipient’s cellphone then depends on the operator.
In addition, there is a screen for sending test messages to the selected recipient; before making such calls, the configuration must
be saved so that the parameters displayed coincide with those that are operative.
 3DUDPHWHUV!3ULQWHU
p1 p2 p3 p4 p5
Printer: Enabled
Funct button:
Value report
Log interval: 10min
Automatic printing
Print events: Yes
Frq. Val. report 15min
Automatic printing
Daily log report
Log interval: 10min
Print time: 9:08
Automatic printing
Grouped daily
report
Enabled
Automatic printing
Weekly log report
Day: Tue
Print time: 11:00
 3ULQWHUFRQILJXUDWLRQ
The initial screen S contains the enabling flag, and the function to attribute to the button on the optional PLWOPPRT00/
PLWOPPRD00 module.
If the enabling flag is deactivated all the print functions will be disabled, and no alarm will be generated relating to the printer or
the optional module.
The button on the printer module can have the following functions:
no action ('LVDEOHG)
immediately print instant value report (9DOXHUHSRUW)
print daily log report ('DLO\ ORJUHSRUW), in this case the parameter /RJLQWHUYDOon the screen allows the sampling interval of the
report to be set (see paragraph “Automatic printing”)
print grouped daily log report (*URXSHGGDLO\ UHSRUW), in this case the parameter /RJLQWHUYDOhas no effect, as the interval is set
to 1 hour.
print weekly log report (:HHNO\ORJUHSRUW), in this case the parameter /RJLQWHUYDOhas no effect, as the interval is set to 1 hour.
Pressing the button for 4 seconds cancels the print in progress and forces a page feed.
The daily prints generated by pressing the button correspond to the current day, and are thus incomplete concerning the values
following the instant the button is pressed.
The weekly prints relate to the week prior to the day of printing, and thus do not include the current day.
 $XWRPDWLFSULQWLQJ
The two configuration screens for automatic printing and set time printing allow the following functions to be enabled and
configured:
printing of the events in real-time (3ULQWHYHQWV)
enabling and frequency of the value report ()UTYDOUHSRUW)
enabling of the daily log report ('DLO\ ORJ UHSRUW), print time and setting the sampling interval for the report (see paragraph
“Automatic printing”)
enabling of the grouped daily log report (*URXSHG GDLO\ UHSRUW). The parameter that establishes the time of the print is the same
for the previous print.
enabling of the weekly log report (:HHNO\ ORJ UHSRUW). The parameters associated to this function are the day of the week and the
print time.
In cases 2, 3 and 5, disabling is represented by the selection “--------“.
