Installation & Maintenance Manual

Part Number Description Drawing Reference

1413107AXX Bottom Drain Pan (SD101,102,103,303,305,308,313) 10

KITVF00000 Bottom Drain Pan (SD323,333,342,360(2),384(2),3B3(3)) 18

1312347AXX Preformed Pipe (Small) 3

1312348AXX Preformed Pipe (Large) 3

1312345AXX Preformed Pipe (MS) 2

1312346AXX Preformed Pipe (MS) 2

KITTC00000 Preformed Pipe (SD323,333,342,360(2),384(2),3B3(3)) 13

13C119A003 Fill Cup (SD 101,102,103,106,303,305,308,313), Ser. #<20000 1,4

13C119A003 Fill Cup (SD 101,102,103,303,305), Ser. #>20000 1,4

KITVCCN000 Fill Cup (SD 106,308,313), Ser. #>20000 1,4

KITCN00000 Conductimeter (SD323,333,342,360,384,3B3) 11

KITTS50001 Kit drain hose (SD323,333,342) 12

KITTS60001 Kit drain hose (SD360,384) 12

KITTS70001 Kit drain hose (SD390,3B3) 12

KITCL00000 Bottom manifold for SD323,333,342,360(2),384(2),3B3(3) 16

1312536AXX Fan for small RDU (VSDC, VRDC)

1312537AXX Fan for small RDU (VSDS, VRDS)

1312535AXX Fan for large RDU (VSDL, VRDL)

1312555AXX Fan for VRDXL RDU (VRDXL)

09C431A019 Main transformer (SD 101,102,103,303,305,308,313)

09C431A020 Main transformer, SD 323,333,342

09C431A021 Main transformer, SD 360,384

09C431A022 Main transformer, SD 3B3

SDFILLCON Quick fill connector (supplied w/each unit) 20

1209587AGM

Cylinder thumb screws (SD101,102,103,106 require 2)

(303,305,308,313 require 3)

1209588AXX Cylinder thumb screws(323 & up) 3 reqd. per cylinder
