Carel SD Installation & Maintenance Manual

SD Carel USA
31
Part Number Description Drawing Reference
R
eplacement Steam C
y
linders:
F201MA0000 1 phase, (SD/OEM-101,102,103) 6
E201MA0000 1 phase, (SD/OEM-106) 6
F401TA0000 3 phase, (SD/OEM-303,305) 6
E401TA0000 3 phase, (SD/OEM-308,313) 6
K400TA0000 3 phase, (SD-323,333,342,360(2),384(2),3B3(3)) 14
H400TA0000 3 phase, (SD-323,333,342,360(2),384(2),3B3(3)) 14
KITH400TA0 Replacemnt electrodes for H400TA 14
ADAH400TA0 Adaptor from K400TA to H400TA
ADAK400TA0 Adaptor from H400TA to K400TA
Cleanable Steam Cylinders:
F200MA000C Cleanable cylinder for SD/OEM-101,102,103 6
F400TA000C Cleanable cylinder for SD/OEM-303,305 6
E401TA000C Cleanable cylinder for SD/OEM-308,313 6
KITF200MAC Replacement electrodes for F201MA000C 6
KITF400TAC Replacement electrodes for F401TA000C 6
KITE400TAC Replacement electrodes for E401TA000C 6
H
umidi
f
ier Controllers:
CDC3030000 On/Off humidifier controller
CDP3030000 Proportional humidifier controller
CDH3030000 Humidity/Prop. hmidifier controller
CDD3030000 CDH controller with dehumidify out.
CDT3030000 CDH with temp input for turkish baths
KITCONNCD0 Connector kit for CD controllers
R
eplacemen
t
Parts:
0203000AXX Power contactor, SD101,102,103,303,305
0203001AXX Power contactor, SD106,308,313
0203007AXX Power contactor, SD323,333,342,360(2),384(2),3B3(3)
0100700AFN Relay for SD 323,333,342
09C412A017 Universal torroid transformer (all models)
AD80000000 Interface board for multicylinder units, AFS
98C277C003 Interface board for multicylinder units, very old version
9995643ACA Drain Valve Kit (SD101,102,103,303,305,308,313) 9
KITPS00000 Drain Pump (SD323,333,342,360(2),384(2),3B3(3)) 17
9995642ACA Fill Valve Kit (SD101,102,103,303,305), Ser. #<20000 8
KITVC00012 Fill Valve Kit (SD106,308,313), Ser. #<20000 8
KITVC00012 Fill Valve Kit (SD101,102,103,303,305), Ser. #>20000 8
KITVC00025 Fill Valve Kit (SD106,308,313), Ser. #>20000 8
KITVC00025 Fill Valve Kit (SD323,333,342,360(2),384(2),3B3(3)), Ser. #<18000 15
KITVC00100 Fill Valve Kit (SD323,333,342,360(2),384(2),3B3(3)), Ser. #>18000 15
9995639ACA Boiler filter w/nut, washer & adapter 7
