Address Type R/W Description of the variables
Interpretation of the data
Default Min Max
4x0010 HR R/W Temperature probe calibration [°C] 0 -90*0.1 90*0.1
4x0050 HR R/W diff erential h 5 1 20
4x0057 HR R/W Humidity sensor calibration [rH%] 0 -20 20
4x0058 HR R/W Diff erential t 0.5 0 50*0.1
4x0129 HR R Terminal fi rmware version 0 0 65535
4x0130 HR R Terminal hardware code 0 0 65535
4x0133 HR R Terminal internal probe temperature 0 -32768 32767
4x0134 HR R Terminal internal probe humidity 0 0 0
4x0140 HR R/W Value selected for the Mode function (Cool/Heat/Fan) 0 0 255
4x0141 HR R/W Value selected for the Fan function 0 0 255
4x0143 HR R/W Value selected for the Power On/Off function 1 0 255
4x0144 HR R/W Temperature set point value 0 HR 0x146 value HR 0x145 value
4x0145 HR R/W Maximum temperature set point 37.0 0 550*0.1
4x0146 HR R/W Minimum temperature set point 5.0 0 550*0.1
4x0151 HR R/W Humidity set point value 55 HR 0x153 value HR 0x152 value
4x0152 HR R/W Maximum humidity set point 70 0 99
4x0153 HR R/W Minimum humidity set point 50 0 99
4x0165 HR R/W LOCK 0 0 65535
4x0249 HR R/W Serial address 1 1 207
4x0250 HR R/W Baud rate 2 0 3
4x0253 HR R/W Menu access password 22 0 9999
4x0255 HR R/W Backlight brightness 4 0 5
4x0340 HR R/W Serial line stop bits 1 0 1
4x0341 HR R/W Serial line parity 0 0 2
4x0350 HR R/W Fan operating mode 0 4 0
4x0360 HR R/W Temperature set point value 0 HR 0x146 value HR 0x145 value
4x0361 HR R/W Temperature set point value 0 HR 0x146 value HR 0x145 value
0x0019 Coil R/W UoM for temp. displayed (0:°C 1:°F) NO value conversion 0 0 1
0x0032 Coil R Generic alarm 0 0 1
0x0051 Coil R/W Relay management confi guration 0 0 1
0x0052 Coil R/W Relay output 0 0 1
0x0056 Coil R/W Enable buzzer 0 0 1
0x0059 Coil R/W Select Mode button 0 0 1
0x0060 Coil R/W Fan - select button 0 0 1
0x0070 Coil R/W Relay output management 0 0 1
Tab. 3.c
