LB.05080.00 Pag.5 16/04/2014
GENERAL CHARACTHERISTICS
MULTI SMART COF MULTI SMART LM
Automatic coffee brewing unit 1 1
Grinder 1 1
Decaffeinated door 1 1
Steam nozzle 1 1
Automatic cappuccino - 1
Hot water dispenser 1 1
Mix Group Optional Optional
Mix cold water Optional Optional
By - Pass Optional Optional
Maximum quantity of coffee dispensed per hour 180 180
Maximum quantity of cappuccino dispensed per hour - 120
Machine Width (mm) 289
Machine height (mm) 592
Machine height with hopper (mm) 814
Machine Depth (mm) 564
Net weight (Kg) 35 35
Boiler capacity (lt) 4 4
Boiler resistor (W) Standard version
Optional version
Optional version
2700+900 (230V~)
2050+710 (200V~)
1200+880 (120V~)
2700+900 (230V~)
2050+710 (200V~)
1200+880 (120V~)
Voltage (V) 230V~ single phase
200V~ single phase
120V~ single phase
230V~ single phase
200V~ single phase
120V~ single phase
Brewer group resistor PTC (W) 70 70
Please note: Multi Smart SELF-version is supplied with hopper with lock and without decaffeinated door and steam
arm.
MACHINES IN SELF CONFIGURATION (see exploded view manual for code number)
Functions are absent or disabled by software:
• extra milk function by pushing the cappuccino/latte dose key: disabled by sw
• function to stop the dose delivery by pushing a dose key: disabled by sw
• function to switch off the machine by pushing Shift and then Info keys: disabled by sw
Included features:
• Kit to block the drip tray
• Kit to block the decaf door
Recommended optionals:
• Lock for beans hoppers
• Direct coffee grounds.
MATERIALS USED:
- Copper for boiler
- Copper and Teflon for hydraulic tubes
- Nickel-plated brass for connections
- Reinforced silicone for the flexible feed tube
- Aluminium with stainless steel lining for the brewing group
- Aluminium for the grinder
- Other accessories in food plastic which are in contact with the ground coffee or drink
- Painted steel bodywork
- ABS plastic for controls area
- Stainless steel and ABS plastic for working area and cups tray.
