Carlisle BINKS E4-100 - Page 24

EN
2
ITEM PART NO.
1

4 162854 Ø82.22 x Ø2.62 O-RING
7 192631 PISTON INLET SEAT 1
QTY REMARKS
Use a 32mm Single Hex
Socket when tightening or
removing ball cage
from Piston.

8
1
DESCRIPTION
160513 CONICAL SPRING 1

162805 Ø63.17 x Ø2.62 O-RING 1

3 162807 Ø50.52 x Ø1.78 O-RING

5 171784 1.75 ST ST BALL 1

193627 BALL CAGE 1
9 194112 Ø114 FLUID PISTON 1
6 192629
1
INLET SPRING KEEP 1

194244 PARTS LIST - Piston Assembly
KEY
(Reverse for assembly)
LOCTITE
TORQUE
MAINTENANCE ORDER
GREASE INTERNAL
(AGMD-010)
GREASE
