BT2 user manual - H-5911-9004-02-B Page | 24
Deploy the Boretrak2 probe 2 m into the borehole. The deployment distance is measured from the nose of the
probe. 2m will take the probe down the borehole so that the second nodule on the steel cable is level with the hole
collar.
With the second nodule against the hole collar, hold the probe still and tap Take Reading.
In the 3D View, the probe progresses 2 m. In the Control tab, the current length of the hole and the number of
Segments (readings taken) are displayed.
The Final Reading and Undo Last buttons become active.
First nodule
on steel cable
Second nodule
on steel cable
level with the
hole collar.
Figure 19 Deploying the probe into the hole
