BT2 user manual - H-5911-9004-02-B Page | 23
Leave the jig in place. Pick up the Boretrak2 probe ready to deploy into Hole 1.
Tap the Zoom to hole button. The 3D View zooms in on the hole selected for survey. An animated model of the
Boretrak2 probe is visible at the hole collar.
Figure 17 Boretrak2 ready to deploy
Figure 18 Zoom in on the selected hole in the 3D View
Take Reading
button
