Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
2 VALVE BOX/ENGINE/ELECTRICAL
DESCRIPTION
ISSUE
R1
REMOTE VALVE SWING HYD, ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
13
PART ITEM DESCRIPTION QTY
1 0300121L Manifold- SP5014TRX Sun 1
2 0300105Z1 HYDRAULIC CYLINDER-2X4 2
3 03002257 3/8 JIC-3/8 ORB - 6400-6-6 4
4 0300219 1/2 JIC-1/2 ORB 90-6801-8 4
5 HSP5014R08 HOSE ASSEMBLY 1
6 HSP5014R10 HOSE ASSEMBLY 1
7 HSP5014R09 HOSE ASSEMBLY 1
8 HSP5014R07 HOSE ASSEMBLY 1
8
7
4
2
4
6
5
3
3
1
2
