Carlyle TS Series User Manual

42
Table 24 — Air-Cooled Motor Data R-134a, R-1234ZE & R-513A (cont)
LEGEND
NOTES:
1. Please contact Carlyle Application Engineering for proper motor pro-
tection device.
2. Delta wiring is not applicable for the selected voltage.
COMPRESSOR BASE
MODELS
MOTOR SIZE
(HP AT 60 Hz)
MOTOR VOLTAGE
(VOLTS-PH-FREQ) RLA
LRA
WYE DELTA
06TTA356 150
460-3-60 226 382 1190
400-3-50 218 388 1210
690-3-50 126 699 NOTE 2
575-3-60 173 306 952
380-3-60 262
462 1441
690-3-60 144 832 NOTE 2
230-3-60 452 764 2380
200-3-50 414 776 2420
200-3-60 497 879 2737
06TUA483 225
460-3-60 314 578 1800
400-3-50 303 587 1828
690-3-50 175 1055 NOTE 2
575-3-60 240 462 1440
380-3-60 363 700 2179
690-3-60 200 1258 NOTE 2
230-3-60 628 1156 3600
200-3-50 576 1174 3656
200-3-60 691 1329 4140
06TUA554 225
460-3-60 360 578 1800
400-3-50 347 587 1828
690-3-50 201 1055 NOTE 2
575-3-60 275 462 1440
380-3-60 417 700 2179
690-3-60 230 1258 NOTE 2
230-3-60 720 1
156 3600
200-3-50 660 1174 3656
200-3-60 792 1329 4140
06TVA680 340
460-3-60 462 623 1900
400-3-50 438 629 1919
690-3-50 555 1108 NOTE 2
06TVA753 340
460-3-60 506 623 1900
400-3-50 487 629 1919
690-3-50 579 1108 NOTE 2
06TVA819 340
460-3-60 517 623 1900
400-3-50 504 629 1919
690-3-50 571 1108 NOTE 2
FREQ — Frequency
HP — Horsepower
LRA — Locked Rotor Amps
PH — Phase
RLA — Rated Load Amps
