Carlyle TS Series User Manual

43
Table 25 — Water-Cooled Motor Data R-134a, R-1234ZE & R-513A
COMPRESSOR BASE
MODELS
MOTOR SIZE
(HP AT 60 Hz)
MOTOR VOLTAGE
(VOLTS-PH-FREQ) RLA
LRA
WYE DELTA
06TTW266 90
460-3-60 124 229 715
400-3-50 120 233 726
690-3-50 69 419 NOTE 2
575-3-60 95 183 572
380-3-60 144 277 866
690-3-60 83 500 NOTE 2
230-3-60 249 458 1430
200-3-50 228 466 1452
200-3-60 274 527 1645
06TTW301 90
460-3-60 139 229 715
400-3-50 134 233 726
690-3-50 77 419 NOTE 2
575-3-60 106 183 572
380-3-60
161 277 866
690-3-60 89 500 NOTE 2
230-3-60 278 458 1430
200-3-50 255 466 1452
200-3-60 306 527 1645
06TTW356 120
460-3-60 161 298 930
400-3-50 155 303 945
690-3-50 90 546 NOTE 2
575-3-60 123 238 744
380-3-60 186 361 1126
690-3-60 107 650 NOTE 2
230-3-60 322 596 1860
200-3-50 295 606 1890
200-3-60 354 685 2139
06TUW483 160
460-3-60 199 408 1270
400-3-50 186 414 1290
690-3-50 108 745 NOTE 2
575-3-60 159 326 1016
380-3-60 240 494 1537
690-3-60 132 888 NOTE 2
230-3-60 397 816 2540
200-
3-50 371 828 2580
200-3-60 457 938 2921
