Carlyle TS Series User Manual

44
Table 25 — Water-Cooled Motor Data R-134a, R-1234ZE & R-513A (cont)
LEGEND
NOTES:
1. Please contact Carlyle Application Engineering for proper motor pro-
tection device.
2. Delta wiring is not applicable for the selected voltage.
COMPRESSOR BASE
MODELS
MOTOR SIZE
(HP AT 60 Hz)
MOTOR VOLTAGE
(VOLTS-PH-FREQ) RLA
LRA
WYE DELTA
06TUW554 160
460-3-60 223 408 1270
400-3-50 209 414 1290
690-3-50 121 745 NOTE 2
575-3-60 179 326 1016
380-3-60
270 494 1537
690-3-60 149 888 NOTE 2
230-3-60 447 816 2540
200-3-50 417 828 2580
200-3-60 514 938 2921
06TVW680 225
460-3-60 280 578 1800
400-3-50 261 587 1828
690-3-50 151 1055 NOTE 2
575-3-60 224 462 1440
380-3-60 338 700 2179
690-3-60 186 1258 NOTE 2
230-3-60 559 1156 3600
200-3-50 522 1174 3656
200-3-60 643 1329 4140
06TVW753 225
460-3-60 310 578 1800
400-3-50 289 587 1828
690-3-50 168 1055 NOTE 2
575-3-60 248 462 1440
380-3-60 375 700 2179
690-3-60 206 1258 NOTE 2
230-3-60 6
19 1156 3600
200-3-50 579 1174 3656
200-3-60 712 1329 4140
06TVW819 225
460-3-60 330 578 1800
400-3-50 308 587 1828
690-3-50 179 1055 NOTE 2
575-3-60 264 462 1440
380-3-60 400 700 2179
690-3-60 220 1258 NOTE 2
230-3-60 660 1156 3600
200-3-50 617 1174 3656
200-3-60 759 1329 4140
FREQ — Frequency
HP — Horsepower
LRA — Locked Rotor Amps
PH — Phase
RLA — Rated Load Amps
