Carrera impel - Battery Removal and Installation; Battery Indicator

EN-6Halfords Carrera Impel
4.3. Battery removal and installation instructions
⚠
CAUTIONS
• Installing the battery carefully is necessary, do not strike it with any tool such as a
hammer or wrenches.
• When storing the battery, please make sure to comply with the storage rules. Find
further information in chapter 7 "Storage and transportation instruction."
• Installation:Insertthebatteryfromthenon-dischargeendrst,thenputtheotherend
in. Complete the installation by pushing the battery to the end until you hear the click.
• Removal: Insert the key and turn it clockwise to lift the battery from the lock end.
4.4. Battery indicator
Hold the indication button for 5 seconds to show the LED indicator light. Each light color
oftheLEDindicatorcorrespondstoadi󰀨erentbatterychargelevel.
LED on in blue
100%-50%
LED on in red
10%-1%
LED on in green
50%-10%
LEDashesinred
0%
