Drain all water from oil cooler coil. See Figure 2. Disconnect water supply line, if already
installed. Remove the drain plug on the waterbox covers and use compressed air to remove
any water from the oil cooler coil. Follow the same procedure with the pumpout unit condenser,
if supplied.
Rigging the Machine
The 19FA machine is rigged as an entire assembly.
Rig Machine Assembly
See rigging instructions on label attached to machine. Refer to Figure 3 and Figure 4 and
Table 1A and Table 1B.
Lift machine only from the 4 points indicated in rigging guide.
Each
lifting cable or chain must be capable of supporting the entire weight of the machine.
A spreader bar may be used to reduce chain height.
Lifting machine from points other than those specified may result in serious dam-
age to the unit and personal injury. Rigging equipment and procedures must be
adequate for machine weight. See Table 1A and Table 1B for machine weights.
Note: These weights are broken down into component sections. For the complete
machine weight, add all component sections and refrigerant charge together. See
Table 1A and Table 1B for machine component weights.
WARNING
!
WARNING
