Make Electrical Connections
Field wiring must be installed in accordance with job wiring diagrams and all applicable
electrical codes.
Wiring information in this publication (Figure 15, Figure 16, Figure 17, Figure 18, Figure 19,
Figure 20, Figure 21, Figure 22, Figure 23, Figure 24 and Figure 25) are for reference only and
are not intended for use during actual installation; follow job specific wiring diagrams.
CAUTION
CAUTION
!
Do not run 120-v wiring into the control center. The control center should only be
used for additional extra low-voltage wiring (50 v maximum).
Do not attempt to start compressor or oil pump (even for a rotation check) or
apply test voltage of any kind while machine is under dehydration vacuum. Motor
insulation breakdown and serious damage may result.
WARNING
!
WARNING
