Condenser Nozzle No.
No. of Pass
In Out
1
20 25
20 26
21 25
21 26
25 20
25 21
26 20
26 21
2
22 20
27 26
22 21
27 25
23 21
23 20
3
24 25
23 25
4
24 21
23 21
Legend
ANSI — American National Standards Institute
RF — Raised Face
CAUTION
!
CAUTION
Figure 10 — Piping Flow Data
(Condenser, Marine Waterboxes)
When the condenser is not a 1- pass arrangement and both the cooler and
condenser have marine waterboxes, the overall height of the unit may need
to be increased to obtain adequate piping clearances.
