Install Water Piping To Oil Cooler
Water supply may be either city water or chilled water. See Figure 12.
City water must be clean and noncorrosive. Water-side erosion or corrosion of the oil cooler
coil may lead to extensive machine damage not covered by the standard warranty.
Click here for Figure 7 — Typical Nozzle Piping
Click here for Figure 8 — Piping Flow Data (Cooler, Marine Waterboxes)
Click here for Figure 9 — Piping Flow Data (Cooler, NIH Waterboxes)
Click here for Figure 10 — Piping Flow Data (Condenser, Marine Waterboxes)
Click here for Figure 11 — Piping Flow Data (Condenser, NIH Waterboxes)
