Legend
MWB — Marine Waterbox
NIH — Nozzle-In-Head Waterbox
*Based on 2 pass NIH waterboxes. If 2 pass MWB are used, add an additional 2,250 lb (1021 kg).
†Based on 2 pass NIH waterboxes. If 2 pass MWB are used, add an additional 2,100 lb (953 kg).
Table 1A — Rigging and Operating Weights — English (lb)
Heat Exchanger Combinations 6032 6032L
Condenser 22,000 28,000
Cooler 31,000 31,000
Economizer 1,900 1,900
Steel Base (includes Storage Tank) 11,000 11,000
Compressor 6,000 6,000
Motor 5,000 5,000
Pumpout 200 200
Suction Elbow 500 500
Miscellaneous Piping 750 750
Control Center 100 100
Total Rigging Weight 78,450 84,450
Refrigerant Charge (HFC-134a) 5,050 5,850
Cooler Water 4,250* 4,250*
Condenser Water 3,100† 4,300†
Total Operating Weight 90,850 98,850
