38MGR-04SM Specifications subject to change without notice. 3
SPECIFICATIONS
Table 2 — Specifications
* Condensing unit above or below the indoor unit.
System
SIZE 18 24 30 36 48
OUTDOOR MODEL 38MGRQ18B--3 38MGRQ24C--3 38MGRQ30D--3 38MGRQ36D--3 38MGRQ48E--3
Max Number of Zones 2 3 4 4 5
Operating
Range
Cooling Outdoor DB
Min - Max
°F (°C)
-13~122
(-25~50)
-13~122
(-25~50)
-13~122
(-25~50)
-13~122
(-25~50)
-13~122
(-25~50)
Heating Outdoor DB
Min - Max
°F (°C)
-22~86
(-30~30)
-22~86
(-30~30)
-22~86
(-30~30)
-22~86
(-30~30)
-22~86
(-30~30)
Piping
Total Piping Length ft (m) 131 (40) 197 (60) 263 (80) 328 (100) 328 (100)
Piping to furthest FCU ft (m) 82 (25) 98 (30) 115 (35) 115 (35) 115 (35)
Drop (OD above ID) ft (m) 49 (15) 49 (15) 49 (15) 65 (20)
Lift (OD below ID) ft (m) 49 (15) 49 (15) 49 (15) 65 (20) 65 (20)
Pipe Connection
Size - Liquid
in (mm)
1/4*2
(6.35*2)
1/4*3
(6.35*3)
1/4*4
(6.35*4)
1/4*4
(6.35*5)
1/4*5
(6.35*5)
Pipe Connection
Size - Suction
in (mm)
3/8*2
(9.52*2)
3/8*3
(9.52*3)
1/2 *1+ 3/8*3
(12.7*1+9.52*3)
1/2 *1+ 3/8*3
(12.7*1+9.52*3)
1/2 *2+ 3/8*3
(12.7*2+9.52*3)
Refrigerant
Type R410A
Charge lbs (kg) 4.41 (2.0) 6.17 (2.8) 6.61 (3.0) 10.13 (4.6) 10.13 (4.6)
Metering Device EEV EEV EEV EEV EEV
Electrical
Voltage, Phase, Cycle V/Ph/Hz 208/230-1-60
Power Supply Indoor unit powered from outdoor unit
MCA A. 18 25 30 35 35
MOCP - Fuse Rating A. 25 35 45 50 50
Compressor
Type Rotary Inverter
Model ATM150D23UFZ ATF235D22UMT ATF310D43UMT ATQ360D1UMU ATQ360D1UMU
Oil Type ESTER OIL VG74
Oil Charge Fl. Oz. 17.64 23.58 35.27 49.38 49.38
Rated Current RLA 10 15 19 21 21
Outdoor Unit
Unit Width in (mm) 37.31 (948) 41.22 (1047) 41.22 (1047) 41.15 (1045) 41.15 (1045)
Unit Height in (mm) 27.64 (702) 31.88 (810) 31.88 (810) 52.48 (1333) 52.48 (1333)
Unit Depth in (mm) 14.82 (376) 17.91 (455) 17.91 (455) 17.63 (448) 17.63 (448)
Net Weight lbs (kg) 105.8 (48) 149.9 (68) 156.5 (71) 221.6 (100.5) 223.8 (101.5)
Airflow CFM 1,390 2,130 2,130 4,500 4,500
Sound Pressure dB(A) 62 63 62 64 64
