38MGR-04SM Specifications subject to change without notice. 81

DISASSEMBLY INSTRUCTIONS SIZE 24 (CONT)

Front panel screws

Right front side

panel screws

Front panel screws

Remove the terminal board

screws (2), the water collector

screws, and the right-rear

panel screws (15) and then

remove the right-rear panel.
