47
Table 23 CCN Device Configuration
NOTE: The device name, description, and location fields can be modified by the
Building Supervisor or ComfortWORK software.
Table 24 Service Configuration
*0 = Disable or Normal
1 = Enable or Inverted
†0 = None
1 =Modulating
2 = Two Position
3 = If applicable, Direct Expansion (DX) for Cooling Type. Electric
Heating for Heating Type.
DEVICE NAME DESCRIPTION LOCATION
SOFTWARE
PART NUMBER
40UV/UH
Comfort
System Unit
Ventilator
CESR-131191-02
DESCRIPTION POINT NAME STATUS / UNITS RANGE DEFAULT
2 Pipe Changeover UNITTYPE Disable/Enable 0 - 1* Disable
ASHRAE Cycle Fan Control CYCLE x 1 - 3† 2
# Fan Speeds (1-3) FAN_TYPE x 1 - 3† 3
Unit Size UNITSIZE xxxx CFM 100 - 5000 1000
% Air Flow Med AFMED * % 30 - 100 80
% Air Flow Low AFLOW* % 20 - 100 70
Fan PID
Kp KP xx.x 0.0 - 40.0 10.0
Ki KI x.x 0.0 - 10.0 3.0
Kd KD xx.x 0.0 - 20.0 0.0
Starting Value STARTVAL xx.x % 0.0 - 100.0 0.0
Cooling Type CV Cooling COOL_TYPx 0-3 0
Kp KP xx.x 0.0 - 40.0 8.0
Ki KI x.x 0.0 - 10.0 0.3
Kd KD xx.x 0.0 - 20.0 0.0
Starting Value STARTVAL xx.x °F 40.0 - 90.0 65.0
Staged Cooling Nr of Stages STAGES x 1 - 2 1
Stg 1 Tim Gard TG1 Disable/Enable 0 - 1* Enable
Stg 2 Tim Gard TG2 Disable/Enable 0 - 1* Enable
Stage 1 Logic Type CLT1 Norm/Invert 0 - 1 Normal
Stage 2 Logic Type CLT2 Norm/Invert 0 - 1* Normal
Heating Type HEAT_TYPx 0-3 0
Heating
Kp KP xx.x 0.0 - 40.0 8.0
Ki KI x.x 0.0 - 10.0 0.3
Kd KD xx.x 0.0 - 20.0 0.0
Starting Value STARTVAL xx.x °F 40.0 - 90.0 80.0
Fan Off Value HCFOV xx.x °F 35.0 - 70.0 55.0
Staged Heating Nr of Stages STAGES x 1 - 2 1
Stg 1 Tim Gard TG1 Disable/Enable 0 - 1* Enable
Stg 2 Tim Gard TG2 Disable/Enable 0 - 1* Enable
Stage 1 Logic Type HLT1 Norm/Invert 0 - 1* Normal
Damper Type MIXDx 0-21
CV Mixed Air Damper
Kp KP xx.x 0.0 - 40.0 8.0
Ki KI x.x 0.0 - 10.0 0.3
Kd KD xx.x 0.0 - 20.0 0.0
Starting Value STARTVAL xx.x °F 40.0 - 90.0 60.0
Air Quality
Kp KPxx.xx 0-1.00.1
Ki KI xx.xx 0 - 1.0 0.03
Max AQOutput AQMDP xxx.x % 0.0 - 100.0 85.0
AQ Low Voltage Volts xx.x Volts 0.0 - 10.0 2.0
AQ High Voltage AQINHI xx.x Volts 0.0 - 10.0 10.0
AQ Low Reference (PPM) AQLO xxxx 0.0 - 5000.0 0.0
AQ High Reference (PPM) AQHI xxxx 0.0 - 5000.0 2000.0
Filter Timer hrs * 100 FIL_TIMRxx 0-99 12
Space Temp Trim RATTRIM xx.x ^F –5.0 - 5.0 0.0
MAT Sensor Trim MAT TR IM xx.x ^F –5.0 - 5.0 0.0
OAT Sensor Trim OATT R IM xx.x ^F –5.0 - 5.0 0.0
